Purpose: Choke valves are versatile medium and severe service choke valves feature cage-guided design for production and separation injection applications due to the ability to fit severe service.

Application: Oil & Gas – Exploration and Production, LNG, Refinery, Petrochemical, Desalination and Power

Size range:

• ASME 1" - 12" ; API 1” – 7 1/16”
• ANSI 150 - 4500. API 2k - 15k

Material grade: Carbon Steel, Stainless Steel, Duplex Stainless Steel, Nickel Alloy and Titanium Alloy

Technical specifications:

• The choke valve is designed and manufactured to meet the requirements of API 6A for Product Specification Levels (PSL) 1, 2, 3 and 4, Material, Temperature, and Performance Ratings.
• The valve incorporates a complete range of trim designs from standard through to multi-cage manufactured from tungsten carbide or advanced ceramic materials for increased erosion resistance.
• The trim is selected to eliminate clogging as appropriate to the fluid contamination.
• These valves are top entry, which ensures that the valves can be easily serviced without removal from the line
